| Main Frame Size |
EIA standard 1/2-rack unit |
| Frequency Range |
VHF 160~250 Mhz |
| Receiving Mode |
Non-Diversity |
| Oscillation Mode |
Quartz Controlled Fixed Frequency |
| Stability |
±0.005% (-10~50°C) |
| Sensitivity |
S/N>76dB@10dB micro V input |
| Max. Deviation Range |
±22KHz |
| S/N Ratio |
>105dB(A) |
| T.H.D. |
<0.5% @ 1KHz |
| Frequency Response |
60Hz~18KHz |
| Squelch Control |
Dual "PiloTone & NoiseLock" |
| Volume Output |
Output level accurately pre-adjusted to mach microphone capsule sensitivity so that users don't need to adjust the volume of receiver. |
| Maximum Output Level |
Three options:+10dBV / 0dBV / -6dBV |
| Power Supply |
External AC Power Supply, 0.5A, 12~15V DC |
| Dimensions |
210(W) × 44(H) × 170(D) mm
8.3(W) × 1.7(H) × 6.7(D) in. |
| Weight |
0.6kg / 1.3lbs. |
| Notes |
Varied specifications on carrier frequency range and maximum deviation to comply regulation of different countries. |
| |
|
| |
