- Modular design for easy installation and maintenance.
- 16 selectable channels available by push of a button.
- Numeric LED clearly indicates working channel.
- High/Low power output selectable.
- LED indicators for RF and audio signal strength.
- Supplies +48V phantom power for true condenser microphone.
- Compatible with ACT-717, ACT-727, ACT-747 & MR-90a receivers.
| |
|
| Frequency Range |
UHF 620~934MHz |
| Bandwidth |
24MHz |
| Oscillation Mode |
PLL Synthesized |
| Channel Grid |
25kHz |
| Frequency Stability |
±0.005%, -10~60℃ |
| Modulation |
FM |
| Output Power |
<100mW (low), <500mW (high) |
| Spurious |
<4nW |
| Frequency Response |
80Hz~15kHz |
| T.H.D. |
<0.5% (at 1kHz, Max. deviation) |
| Audio Input |
XLR/6.3mmØ Combo jack |
| Input Sensitivity |
Mic or Line level |
| Input Sensitivity Control |
Adjustable control for input gain |
| Phantom Power Switch |
ON / OFF |
| Panel Display |
AF Meter, AF Limit, RF Hi/Low Power indicators, numeric channel. |
| Antenna Connector |
TNCx1 (50Ω impedance) |
| Dimensions |
210(W)×44(H)×206(D) mm / 8.3(W)×1.7(H)×8.1(D)" |
| Weight |
Approx. 1.1kg / 2.4lbs |
| Note |
Refer to actual product in the event of product discrepancy. |
| |
| |
|
|
|
|
|
 |
 |
 |
|
| ACT-717 |
ACT-727 |
ACT-747 |
MR-90a |
|
| |
|
|
|
|
| |
|
|
|
|
 |
 |
|
|
|
FB-71
|
FB-72 |
|
|
|
| |
|
|
|
|
|
|
